FWD-50PX1N: Loosen the two screws
located on the top and bottom of the
panel cover. Use a Philips
screwdriver to turn the screws
counterclockwise, and then remove
the panel cover.
Preparations for Using the Networking Function
CONTR
OL S
REMO
TE
IN
OUT
1
1
2
When the option slot is located
on the right side*
* The location of the option slot differs
depending on the model of the Display
Unit. Refer to the Instruction Manual of
the FWD series as well.
2
Check the direction (top/bottom) of
this device and insert it into the flat
panel display. Make sure that the
connector inside the display is firmly
connected.
Using a slot screwdriver, tighten the
two screws of this device. Connect the
LAN cable, as needed.
Caution
Do not touch the connectors in the Display.
Doing so may result in injury to yourself or
cause this device to malfunction.
CONTR
OL S
REMO
TE
IN
OUT
2
2
1
NETW
ORK MANA
GEMENT
