Dimensions in mm and weights
16
EB 5766 EN
Dimensions in mm and weights
Nominal size
DN
15
20
25
32
40
50
Thread size
G
½
¾
1
–
–
–
Pipe
Ød
21.3
26.8
33.7
42
48
60
Thread size
R
G ¾
G 1
G 1¼
G 1¾
G 2
G 2½
Width across flats
SW
30
36
46
59
65
82
Length
L
65
70
75
100
110
130
Length with welding ends
L1
210
234
244
268
294
330
Height
H2
45.5
94
Versions for temperatures up to 200 °C
and with intermediate insulating piece
140
185
Height H3
30
55
Weight without actuator
approx. kg
1.4
1.8
2.3
4.0
4.4
6.8
Versions for temperatures up to 200 °C
and with intermediate insulating piece
1.9
2.3
2.8
4.5
4.9
7.3
Version with threaded ends (male thread)
Length
L2
129
144
159
180
196
228
Male thread
A
G ½
G ¾
G 1
G 1¼
G 1½
G 2
Weight without actuator
approx. kg
1.4
1.8
2.3
4.0
4.4
6.8
Versions for temperatures up to 200 °C
and with intermediate insulating piece
1.9
2.3
2.8
4.5
4.9
7.3
Version with flanges
Length
L3
130
150
160
180
200
230
Weight without actuator
approx. kg
2.5
3.4
4.1
6.9
7.7
10.7
Versions for temperatures up to 200 °C
and with intermediate insulating piece
3.0
3.9
4.6
7.4
8.2
11.2
Version with female thread
Length
L4
65
75
90
–
Female thread
G
G ½
G ¾
G 1
–
Weight without actuator
approx. kg
1.2
1.4
1.5
–
Versions for temperatures up to 200 °C
and with intermediate insulating piece
1.7
1.9
2.0
–
Version with flanged valve body
Height
H2
45.5
94
Length
L3
130
150
160
180
200
230
Weight without actuator approx. kg
2.5
3.4
4.1
6.9
8.4
11.6
Versions for temperatures up to 200 °C
and with intermediate insulating piece
3.0
3.9
4.6
7.4
8.9
12.1
