Form No. 702718 Rev. A March, 2005 77
Owner’s Manual - Regal Intensive Care Unit
Latch Connector
Rest
P/N 618472
There is a latch connector rest on each animal compartment door.
The rests are identical and are removed and installed the same way.
The rests can be replaced without removing the doors from the unit.
Tools Required
„ 11/32-in. wrench
„ Flat-blade screwdriver
Procedure
1. Open the door.
2. With a flat-blade screwdriver and a 11/32-in. wrench,
remove the two screws/nuts that hold the rest to the door
(Figure 85), and remove the rest.
3. Hold the new rest in place and secure with the two screws/
nuts. Snug the screws down tightly, but be careful not to
crack the clear acrylic panel.
Figure 85. Latch Connector Rest
Screws/Nuts
(2)
