Connecting the cables to the outdoor unit, As12a5(a6)mc, As18a5(a6)rc – Samsung AS07A5(A6)MA User Manual
Page 37
E-
37
ENGLISH
I
NSTALLING THE
O
UTDOOR
U
NIT
Connecting the Cables to the Outdoor Unit
One electric cable must be connected to the outdoor unit:
◆ The assembly cable connecting the indoor unit to the outdoor unit
1
Remove the terminal board cover on the side of the outdoor unit.
2
Connect the assembly cable to terminals as shown in the figure.
➢
Each wire is labelled with the corresponding terminal number.
➢
Each wire from the terminal number of the indoor unit.
Shall be comected with the same terminal number of its
outdoor unit.
3
Connect the earth wires to the earth terminals.
➢
Refer to the page 39 for further details on how to check
that earthing is correct.
4
Replace the terminal board cover, carefully tightening the screw.
✴✴
07/09
✴✴
AS12A5(A6)MC
✴✴
18/24
✴✴
AS12AA(AB)MC
N
L
1
2
3
N1 1
2
3
N
L
1
L
N
E
L
1
E
N
E
L
E
N
Indoor
unit
Outdoor
unit
Earth
terminal
Circuit Breaker(Main Power)
AS12A5(A6)MC
A
B
1
2
3
4
L1 L2
A
B
1
2
3
4
2
1
E
2
1
E
E
E
A
B
A
B
L2
L1
Indoor
unit
Outdoor
unit
Earth
terminal
Circuit Breaker(Main Power)
AS18A5(A6)RC
A
B
1
2
3
4
L1 L2
A
B
1
2
3
4
3
2
1
E
3
2
1
E
E
E
L1
L2
A
B
A
B
Indoor
unit
Outdoor
unit
Earth
terminal
Circuit Breaker(Main Power)
AS18A9(A0)RCD / AS24A1(A2)RC
L1 L2
1
2
3
(A) 1
L1 L2
1
E
L2
1
E
L1
L2
L1
E
E
L2
L1
Indoor
unit
Outdoor
unit
Earth
terminal
Circuit Breaker(Main Power)
✴✴
07/09
✴✴
/ AS12AA(AB)MC
