C106 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
C107 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C108 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
C109 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C11 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C110 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C111 2203-005171 C-CERAMIC,CHIP;1uF,10%,16V,X7R,TP,2012,-
C112 2203-005171 C-CERAMIC,CHIP;1uF,10%,16V,X7R,TP,2012,-
C113 2203-005171 C-CERAMIC,CHIP;1uF,10%,16V,X7R,TP,2012,-
C114 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C115 2203-000800 C-CERAMIC,CHIP;33nF,10%,25V,X7R,TP,1608
C116 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C117 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C118 2402-001071 C-AL,SMD;220uF,20%,10V,GP,TP,8.3x8.3x6.
C119 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C12 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C120 2203-005171 C-CERAMIC,CHIP;1uF,10%,16V,X7R,TP,2012,-
C121 2203-005171 C-CERAMIC,CHIP;1uF,10%,16V,X7R,TP,2012,-
C14 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C16 2203-001086 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP
C2 2203-001086 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP
C201 2402-000179 C-AL,SMD;47uF,20%,16V,GP,TP,6.6x6.6x5.4
C202 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C203 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C204 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C205 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C206 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C207 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C208 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C209 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C210 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C211 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C212 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C213 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C214 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C215 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C216 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C217 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C218 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C219 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C220 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C221 2402-000179 C-AL,SMD;47uF,20%,16V,GP,TP,6.6x6.6x5.4
C222 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C223 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C224 2402-000179 C-AL,SMD;47uF,20%,16V,GP,TP,6.6x6.6x5.4
C225 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C226 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C3 2203-001086 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP
C5 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C6 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C7 2203-000704 C-CERAMIC,CHIP;0.002nF,0.25pF,50V,RH,TP,
C9 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
J101 MF70-00193A SHIELD;EUROSTAR,ET (#50-50),0.4,-,54,
J201 3711-004724 CONNECTOR-HEADER;NOWALL,31P,1R,2.5mm,ANG
L102 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L103 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L104 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L105 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L201 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L202 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
Q1 0501-000519 TR-SMALL SIGNAL;BFP183,NPN,450mW,SOT-143
R1 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R101 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R102 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
R105 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
R2 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R201 2007-000971 R-CHIP;5.1ohm,5%,1/16W,DA,TP,1608
R202 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
R203 2007-000729 R-CHIP;300ohm,5%,1/16W,DA,TP,1608
R204 2007-000729 R-CHIP;300ohm,5%,1/16W,DA,TP,1608
R205 2007-000729 R-CHIP;300ohm,5%,1/16W,DA,TP,1608
R206 2007-000729 R-CHIP;300ohm,5%,1/16W,DA,TP,1608
R207 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
R208 2007-000729 R-CHIP;300ohm,5%,1/16W,DA,TP,1608
R209 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R210 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R211 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R212 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R3 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R4 2007-000028 R-CHIP;39OHM,5%,1/10W,DA,TP,2012
R5 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
R6 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
R8 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
R9 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
T101 MD26-00107A TRANS;BTB003-1,-,5P,5.6uH,-,-,-,-,-,
U1 1204-001686 IC-TUNER;1821,QFP,48P,276MIL,PALSTIC,5.
U2 1204-001685 IC-DECODER;HM1221,QFP,100P,-,PLRASTIC,3.
Y1 2801-004002 CRYSTAL-UNIT;10.111MHz,30ppm,28-AAA,20pF
T801 3722-001345 JACK-SCART;42P/2R,-,SN,BLK,-
T802 3722-001735 JACK-PIN;4P/4C,8.3PI,NI,WHT/YEL/RED/BLK
U100 1204-001809 IC-ENCODER/DECODER;STI5512AWE,BGA,256P,1
U1004 1203-000157 IC-POSI.ADJUST REG.;317,TO-220,3P,-,PLAS
U101 0801-002536 IC-CMOS LOGIC;74LCX04,INVERTER,SOIC,14P,
U102 1203-001758 IC-RESET;1813,SOT-23,3P,-,PLASTIC,-0.5/
U103 0801-001090 IC-CMOS LOGIC;74HC14,SCHIMITT INVERTER,S
U104 0803-000111 IC-TTL;74F138,1-OF-8 ENCODER/DEMUX,SO
U105 0801-002370 IC-CMOS LOGIC;74AC377,D FILP-FLOP,TSSOP,
U106 0801-002370 IC-CMOS LOGIC;74AC377,D FILP-FLOP,TSSOP,
U108 1107-001238 IC-FLASH MEMORY;29LV160,2Mx8/1Mx16Bit,TS
U112 1105-001390 IC-DRAM;K4S641632F,4X1MX16BIT,TSOP(II)
U113 1103-001090 IC-EEPROM;24C128,16Kx8BIT,SOP,8P,150MIL,
U114 1103-001090 IC-EEPROM;24C128,16Kx8BIT,SOP,8P,150MIL,
U201 1006-000347 IC-LINE TRANSCEIVER;202,SOP,16P,150MIL,D
U500 0904-001568 IC-PHERIPHERAL CONT.;CIMAX VER.2,8BIT,QF
U501 0802-001037 IC-BICMOS LOGIC;74LVT245,BUS TRANSCEIVER
U502 0801-002511 IC-CMOS LOGIC;74VHC373,D-type latch,TSSO
U503 0801-002511 IC-CMOS LOGIC;74VHC373,D-type latch,TSSO
U504 1203-001834 IC-VOL. DETECTOR;1478,SOP,16P,150MIL,PLA
U70 1203-001455 IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P
U700 1002-001059 IC-D/A CONVERTER;CS4330-KS,18BIT,SOP,8P,
U701 1201-000167 IC-OP AMP;358,SOP,8P,150MIL,DUAL,100V/mV
U71 1203-001455 IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P
U72 1203-000273 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLAS
U750 1205-002067 IC-TRANSMITTER;STA020D,SO,24P,295MIL,-,3
U801 1001-000172 IC-ANALOG SWITCH;4053,SPDT CMOS,SOP,16P,
VD100 0405-000117 DIODE-VARACTOR;1SV215,30V,10nA,USC,TP
VD101 0405-000117 DIODE-VARACTOR;1SV215,30V,10nA,USC,TP
X100 2801-003365 CRYSTAL-UNIT;27MHZ,20PPM,28-AAM,17PF,35O
X1001 1404-000154 THERMISTOR-PTC;0.47ohm,-,-,60Vac,40A,1.8
X800 1404-000233 THERMISTOR-PTC;0.48ohm,-,-,60Vac,40A,1.3
3 MF95-10004F MAIN PCB ASSY;SRV20901FA,DSR9500(VIA)
SC600 3709-001132 CONNECTOR-CARD EDGE;20P,2.54MM,ANGLE,AUF
BD103 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
BD104 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
BD105 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
BD106 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
BD107 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
BD108 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
BD109 2203-001002 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,201
BD110 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
BD70 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
Electrical Parts List
Samsung Electronics 6-11
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
