Samsung DSR9500EMVIA - Manual (Page 12)

C803 2203-001002 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,201
C804 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
C805 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
C806 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C807 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C808 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C809 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C810 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
C811 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
C812 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C813 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C814 2203-001002 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,201
C815 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
C816 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
C817 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
C818 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C819 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C820 2203-001002 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,201
C822 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
C823 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
C824 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
C828 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C829 2203-001002 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,201
C835 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CON501 3709-001141 CONNECTOR-CARD EDGE;136P,1.27mm,ANGLE,AU
CP101 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP400 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP401 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP402 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP404 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP405 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP406 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP500 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP501 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP502 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP503 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP70 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP700 2401-001529 C-AL;47uF,20%,25V,GP,-,5x11,2mm
CP703 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
CP704 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP708 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP71 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP710 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
CP711 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP713 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP72 2401-000010 C-AL;220uF,20%,16V,GP,-,6.3x11mm,2.
CP73 2401-000010 C-AL;220uF,20%,16V,GP,-,6.3x11mm,2.
CP74 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP801 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP802 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP803 2401-000010 C-AL;220uF,20%,16V,GP,-,6.3x11mm,2.
CP804 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP805 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP806 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP807 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP808 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP809 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP810 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP813 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP814 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP815 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP816 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP817 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP818 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
CP819 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
CP820 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP821 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP823 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP824 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP825 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP826 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP827 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
CP828 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP829 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP830 2401-000273 AL CAPACITOR;100uF,20%,16V,GP,-,6.3x11,2
CP831 2401-000677 C-AL;2200uF,20%,10V,GP,TP,10x20mm,5
CP832 2401-000677 C-AL;2200uF,20%,10V,GP,TP,10x20mm,5
CP833 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP834 2401-001287 C-AL;47uF,20%,16V,GP,TP,5x12mm,-
CP835 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
CP836 2401-000010 C-AL;220uF,20%,16V,GP,-,6.3x11mm,2.
D1002 0402-000129 DIODE-RECTIFIER;1N4003,200V,1A,DO-41,TP
D1003 0402-000129 DIODE-RECTIFIER;1N4003,200V,1A,DO-41,TP
D801 0401-000133 DIODE-SWITCHING;RLS4148,100V,200MA,SOD-8
D804 0401-000133 DIODE-SWITCHING;RLS4148,100V,200MA,SOD-8
D805 0401-000133 DIODE-SWITCHING;RLS4148,100V,200MA,SOD-8
D806 0401-000133 DIODE-SWITCHING;RLS4148,100V,200MA,SOD-8
D807 0401-000133 DIODE-SWITCHING;RLS4148,100V,200MA,SOD-8
D815 0501-000462 TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT-
D816 0403-001390 DIODE-ZENER;RLZ18B,16.82-17.7V,500mW,LL-
D817 0403-001390 DIODE-ZENER;RLZ18B,16.82-17.7V,500mW,LL-
DB201 3701-000320 CONNECTOR-DSUB;9P,2R,FEMALE,ANGLE,AUF
J100 3711-002633 CONNECTOR-HEADER;NOWALL,2P,1R,2.54mm,STR
J103 3711-000754 CONNECTOR-HEADER;BOX,20P,2R,2.54mm,STRAI
J104 3711-000577 CONNECTOR-HEADER;BOX,10P,1R,2.5mm,STRAIG
J400 MF39-00014A SUPER VIDEO-JACK;4016-4P-MR,-,-,-,-,-,-,
J70 3711-003133 CONNECTOR-HEADER;BOX,13P,1R,2.5mm,STRAIG
J801 0603-001051 OPTIC TRANSMITTER;5V,6Mb/s,5m,-15dBm,660
JR100 3404-001064 SWITCH-TACT;12V,50mA,160gf,6x6x3.5mm,-
L1002 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L101 2703-000125 INDUCTOR-SMD;10uH,10%,1.25x2x1.25mm
L102 2703-000125 INDUCTOR-SMD;10uH,10%,1.25x2x1.25mm
L103 MF27-00010D HZ CHIP INDUCTOR;-,2.0x1.25x0.9,-,-,-,-,
L104 2703-000125 INDUCTOR-SMD;10uH,10%,1.25x2x1.25mm
L106 2703-000125 INDUCTOR-SMD;10uH,10%,1.25x2x1.25mm
L700 2703-000125 INDUCTOR-SMD;10uH,10%,1.25x2x1.25mm
L801 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L802 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
L803 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
L804 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
L805 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
L806 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
L807 2703-000229 INDUCTOR-SMD;6.8UH,20%,1.25X2X1.25MM
MOD801 MF40-00129A RF MODULATOR;RMUP74055FS(S),PAL,40CHANNE
Q1006 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1007 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1008 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1009 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1010 0502-000360 TR-POWER;TIP42C,PNP,65000MW,TO-220,TP,1
Q1010 MF62-00001B HEAT-SINK;A6063,11X15X20,-,-,-,-
Q1011 0502-000360 TR-POWER;TIP42C,PNP,65000MW,TO-220,TP,1
Q1012 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
Q1015 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1023 0501-000316 TR-SMALL SIGNAL;KSA928A-Y,PNP,1000mW,TO-
Q1024 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1025 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q1026 0504-000180 TR-DIGITAL;DTC114ES,NPN,300mW,10K/10K,SC
Q400 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
Q401 0501-000462 TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT-
Q402 0501-000462 TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT-
Q403 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
Q701 0501-000462 TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT-
Electrical Parts List
Samsung Electronics 6-7
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
