Sim2 Multimedia GRAND CINEMA HT HT5000 - Manual (Page 23)

ht5000
f1-f2 keys
The remote control is equipped with two keys (F1 and F) which
are associated with various different functions.
The screen has six options, one for each line, and two columns
indicating the keys F1-F. You can select F1 and F with the keys
◀
and ▶ on the remote control; select the function to assign
to F1 or F with the keys ▼ and ▲.
The function performed by the key is confirmed by the appea-
rance of a dot on the corresponding column-row intersection
(Fig 5).
The following menu options are available.
Zoom
Accesses the lens zoom, so that ◀ and ▶ zoom into and out
The FOCUS setting drives the motorized focus to focus the
image; precise focus should enable you to see every pixel in
the image when close to the screen.
focus
This option enables you to use the ◀ and ▶ keys to focus the
image.
Magnification
Activates the electronic zoom, the keys ◀ and ▶ zoom into the
image. If the key is pressed a second time you will activate PAN
mode in which the ◀ and ▶, ▼ and ▲ keys enable you to pan
over the magnified image.
At the third pression of F1 or F key, the system reconfigures the
projector to original visualisation settings.
Blank
Switches off the video signal and displays a black page. As
soon as the key is pressed an OSD indication lasting a few se-
conds confirms that the function has been activated. Pressing
any further keys on the remote control restores the previous
conditions.
Color Temperature
Successive pressing F1 or F key makes it possible to select
among the available color temperature setting.
gamma Correction
Successive pressing F1 or F key makes it possible to select
from among the available gamma curves.
SOURCE iNfORMATiON
When active (YES) each time the source is changed informa-
tion is displayed relative to the signal type. If inactive, (NO) no
information about the source is displayed.
OSD BACKgROUND
Determines the type of background for the On Screen Display
(opaque or transparent).
OSD TiMEOUT
Determines the On Screen Display timeout. The adjustment is
made using the ◀ (decrease) and ▶ (increase) keys within a
6-00 second timeframe.
OSD POSiTiON
Allows the On Screen Display to be positioned in a particular area
of the projected image. The OSD can be positioned using the
arrow keys for fine adjustments or using keys 1...9 on the remote
control to select one of nine preset positions.
Source list
F1/F2 keys
Source info
OSD Backgroung
OSD Position
OSD Timeout
Language
Menu
English
Zoom
Focus
Magnification
Blank
Gamma correction
Color temperature
F1 F2
Fig.5
MEMORiES
The main picture parameters can be saved in discrete sets
of values called “Memories” so that they can be subsequently
applied as a group using a single command.
There are 6 distinct Memories (Memory 1,...6) for each of the
14 signal types managed.
The image parameters that can be saved/recalled by the
Memories management system are the following:
image Picture
BRIGHTNESS ASPECT
CONTRAST COLOR TEMPERATURE
COLOUR OVERSCAN
TINT GAMMA
SHARPNESS
FILTER
NOISE REDUCTION
