System Requirements

Pentium

®

or equivalent computer with an available

PCI slot

Windows

®

7 (32-/64-bit) / Vista (32-/64-bit) / XP

(32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2000

/ ME / 98SE / 98 / 95, DOS

Package Contents

2S1P Combo-Value board

2-Port DB9 (9-pin) serial port cable

Driver CD

Quick installation guide

Layout

Figure 1. 2S1P Combo-Value

Note: When connecting the 2-Port DB9 serial

port cable, position the ribbon cable(s) so that

the stripe is on the side farthest away from the

parallel port. See Figure 1.

2-Port DB9 serial port cable

Parallel port

Stripe
