Connecting speakers – Sony 3-289-204-42(3) User Manual
Page 16
16
GB
D:\NORM'S JOB\SONY HA\SO0054\STR-DA2400ES\CEL VERSION\3289204423\04GB-
STRDA2400ESUC\030CON_GB.fm
masterpage: Left
STR-DA2400ES
3-289-204-42(3)
2: Connecting speakers
Before connecting cords, make sure to
disconnect the AC power cord (mains lead).
AFront speaker A (left)
BFront speaker A (right)
CCenter speaker
DSurround speaker (left)
ESurround speaker (right)
FSurround back speaker (left)
b)
GSurround back speaker (right)
b)
HSubwoofer
c)
10 mm
H
D
G
A
C
E
F
B
B
A
SPEAKERS FRONT
B terminals
a)
A
Speaker cords (not supplied)
B
Monaural audio cord (not supplied)
A
A
A
