63
R
Section 8
Ref.
No.
Part No. Description
1 484286 Fuel Cap w/ Tethered
2 484279-01 Tube, Fuel Tank Insert
3 462296 Fuel Tank RH (incl. #7 & #8)
4 04030-03 Lockwasher, 5/16" Spring
5 04001-08 Bolt, Hex Head 5/16-18 x 3/4"
6 04040-15 Flatwasher, 5/16-.375 x .875 x .083
7 482571 Tank Bushing
8 483748 Fitting, 90 Degree
9 483617 Fuel Hose, 1/4" I.D. Non-Perm (order by inch)
10 423912 Bracket, Fuel Valve
11 482212 Fuel Shutoff Valve
12 * Fuel Filter
13 462295 Fuel Tank LH (incl. #7 & #8)
14 484342 Carbon Canister
15 484347 Hose, 3/16" (order by inch)
16 48136-17 Clamp
17 452176 Bracket, Canister Mounting
18 48935-02 T - Fitting, Fuel Vent
19 484284 Valve, Rollover
20 484285 Grommet, Viton
21 48059-05 Clamp, Vapor Recovery Hose 3/16"
22 48059-02 Clamp, Fuel Hose
23 484343-01 Mender, 1/4 x 3/16 w/.02 Hole
24 425559 Heatshield
25 484347 Hose, 1/4" Vapor Recovery (order by inch)
* = Available through engine manufacturer only.
STC FUEL SYSTEM - EPA PHASE 3
(models produced after 1/1/2011)
