47
R
Section 8
STC FOLDABLE ROLL-OvER PROTECTION SYSTEM
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10 462209
484168
484170
484169
04001-90
04021-19
484167
04021-19
04040-13
04001-145 STC Foldable ROPS
Pin Assembly (incl. #3 & #4)
Spring, ROPS
Clip, ROPS
Bolt, Hex Head 1/2-13 x 3-1/4"
Nut, Center Lock 1/2-13
Spring Clip, ROPS
Nut, Center Lock 1/2-13
Flatwasher, 1/2-.562 x 1.375 x .109
Bolt, Hex Head 1/2-13 x 3-1/2"
