Sears 486.248463 - Manual (Page 21)

21
REPAIR PARTS FOR MODEL 486.248463 46" SNOW THROWER
REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION
NO. NO.
1 63576 1 Housing Assembly 1 63576 1 Housing Assembly
2 64517 1 Impeller Assembly 2 64517 1 Impeller Assembly
3 47368 2 Spring Pin, 5/16" x 1-3/4" 3 47368 2 Spring Pin, 5/16" x 1-3/4"
4 47369 2 Spring Pin, 3/16" x 1-3/4" 4 47369 2 Spring Pin, 3/16" x 1-3/4"
5 63772 1 Spiral Assembly, R.H. 5 63772 1 Spiral Assembly, R.H.
6 63771 1 Spiral Assembly, L.H. (Not Shown) 6 63771 1 Spiral Assembly, L.H. (Not Shown)
7 618-04045 1 Auger Gear Assembly 7 618-04045 1 Auger Gear Assembly
8 24308 1 Gear Housing Support Plate 8 24308 1 Gear Housing Support Plate
9 784-5076 1 Gear Housing Support Bracket 9 784-5076 1 Gear Housing Support Bracket
10 46703 1 Bolt, Self Thd., 5/16-18 x 3/4" 10 46703 1 Bolt, Self Thd., 5/16-18 x 3/4"
11 R19111116 7 Flat Washer, 11/32" x 11/16" 11 R19111116 7 Flat Washer, 11/32" x 11/16"
12 43063 3 Hex Bolt, 5/16-18 x 1" 12 43063 3 Hex Bolt, 5/16-18 x 1"
13 43064 38 Hex Lock Nut, 5/16-18 Thd. 13 43064 38 Hex Lock Nut, 5/16-18 Thd.
14 43086 30 Lockwasher, 5/16" 14 43086 30 Lockwasher, 5/16"
15 24913 1 Bearing Offset Bracket 15 24913 1 Bearing Offset Bracket
16 48593 1 Spacer 16 48593 1 Spacer
17 47598 6 Flanged Lock Nut, 1/4-20 Thd. 17 47598 6 Flanged Lock Nut, 1/4-20 Thd.
18 24942 1 Belt Keeper Bracket 18 24942 1 Belt Keeper Bracket
19 24941 1 Belt Cover 19 24941 1 Belt Cover
20 47810 12 Nylock Nut, 5/16-18 20 47810 12 Nylock Nut, 5/16-18
21 47044 2 V-Pulley, Idler 21 47044 2 V-Pulley, Idler
22 05845B 2 Bearing Housing 22 05845B 2 Bearing Housing
23 24911 1 Idler Bracket, L.H. 23 24911 1 Idler Bracket, L.H.
24 24910 1 Idler Bracket, R.H. 24 24910 1 Idler Bracket, R.H.
25 24912 1 Cross Tie Bracket 25 24912 1 Cross Tie Bracket
26 48595 1 Key, 3/16" x 3/4" 26 48595 1 Key, 3/16" x 3/4"
27 43353 2 Lockwasher, 1/2" 27 43353 2 Lockwasher, 1/2"
28 43262 2 Hex Lock Nut, 1/2-13 Thd. 28 43262 2 Hex Lock Nut, 1/2-13 Thd.
29 711-0242 2 Spacer 29 711-0242 2 Spacer
30 44917 1 Palnut, 3/8" 30 44917 1 Palnut, 3/8"
31 24309 1 Wear Plate 31 24309 1 Wear Plate
32 43080 20 Carriage Bolts, 5/16-18 x 3/4" 32 43080 20 Carriage Bolts, 5/16-18 x 3/4"
33 43081 16 Flat Washer, 5/16" 33 43081 16 Flat Washer, 5/16"
34 24279 2 Skid Shoe 34 24279 2 Skid Shoe
35 G586868 2 Leveling Shoe 35 G586868 2 Leveling Shoe
36 24481 2 Skid Shoe Bracket 36 24481 2 Skid Shoe Bracket
37 43001 8 Hex Bolt, 3/8-16 x 1" 37 43001 8 Hex Bolt, 3/8-16 x 1"
38 43003 18 Lockwasher, 3/8" 38 43003 18 Lockwasher, 3/8"
39 43082 17 Hex Lock Nut, 3/8" 39 43082 17 Hex Lock Nut, 3/8"
40 44326 10 Carriage Bolt, 5/16-18 x 1" 40 44326 10 Carriage Bolt, 5/16-18 x 1"
41 48570 1 Bearing, Self Aligning 41 48570 1 Bearing, Self Aligning
42 48572 1 Pulley, 9" 42 48572 1 Pulley, 9"
43 710-0696 1 Hex Bolt, 3/8-24 x 7/8" 43 710-0696 1 Hex Bolt, 3/8-24 x 7/8"
44 736-0247 1 Flat Washer, 3/8" x 1-1/4" 44 736-0247 1 Flat Washer, 3/8" x 1-1/4"
45 731-1696 1 Discharge Chute Adapter 45 731-1696 1 Discharge Chute Adapter
46 784-5711 1 Chute Bracket, 6" 46 784-5711 1 Chute Bracket, 6"
47 48015 5 Nylon Washer, 5/8" 47 48015 5 Nylon Washer, 5/8"
48 731-0903D 1 Lower Discharge Chute 48 731-0903D 1 Lower Discharge Chute
49 731-0846C 1 Upper Discharge Chute 49 731-0846C 1 Upper Discharge Chute
51 731-1313C 1 Cable Guide 51 731-1313C 1 Cable Guide
52 784-5594 1 Cable Bracket 52 784-5594 1 Cable Bracket
53 746-0928 1 Chute Control Cable 53 746-0928 1 Chute Control Cable
54 746-0929 1 Chute Control Cable w/Clip 54 746-0929 1 Chute Control Cable w/Clip
55 43085 1 Hex Bolt, 5/16-18 x 1-1/2" 55 43085 1 Hex Bolt, 5/16-18 x 1-1/2"
56 710-0896 1 Hex Screw, 1/4-14 x 5/8" 56 710-0896 1 Hex Screw, 1/4-14 x 5/8"
57 741-0475 2 Plastic Bushing, 3/8" 57 741-0475 2 Plastic Bushing, 3/8"
58 684-0061 1 Chute Crank Assembly 58 684-0061 1 Chute Crank Assembly
REF. PART QTY. DE SCRIP TION REF. PART QTY. DE SCRIP TION
NO. NO. NO. NO.
REF. PART QTY. DE SCRIP TION
NO. NO.
59 784-5149 1 U-Joint 59 784-5149 1 U-Joint
60 43850 2 Roll Pin, 1/8" x 5/8" 60 43850 2 Roll Pin, 1/8" x 5/8"
61 43070 10 Flat Washer, 3/8" 61 43070 10 Flat Washer, 3/8"
62 24300 1 Chute Crank Bracket, Rear 62 24300 1 Chute Crank Bracket, Rear
63 24299 1 Chute Crank Bracket, Front 63 24299 1 Chute Crank Bracket, Front
64 64504 1 Idler Arm Assembly 64 64504 1 Idler Arm Assembly 64 64504 1 Idler Arm Assembly
65 24286 1 Pivot Spacer 65 24286 1 Pivot Spacer
66 63762 1 Idler Bracket Assembly 66 63762 1 Idler Bracket Assembly
67 24472 1 Pivot Spacer 67 24472 1 Pivot Spacer
68 48883 2 Flat Pulley 68 48883 2 Flat Pulley
69 47044 1 V-Idler Pulley, 4" 69 47044 1 V-Idler Pulley, 4"
70 47064 1 V-Pulley, 5.9" 70 47064 1 V-Pulley, 5.9"
71 48102 1 V-Pulley, 10" 71 48102 1 V-Pulley, 10" 71 48102 1 V-Pulley, 10"
72 738-0680 1 Shaft 72 738-0680 1 Shaft
73 750-0456 1 Spacer 73 750-0456 1 Spacer
74 750-0660 1 Spacer 74 750-0660 1 Spacer
75 714-0161 2 Key 75 714-0161 2 Key
76 741-0919 2 Ball Bearing 76 741-0919 2 Ball Bearing
77 08253B 1 Bearing Housing 77 08253B 1 Bearing Housing 77 08253B 1 Bearing Housing
78 15296A 1 Bearing Housing, Open 78 15296A 1 Bearing Housing, Open
79 14088B 1 Spindle Spacer 79 14088B 1 Spindle Spacer
80 44377 2 Hex Bolt, 3/8-24 x 1" 80 44377 2 Hex Bolt, 3/8-24 x 1"
81 736-0247 2 Flat Washer, 3/8" x 1-1/4" 81 736-0247 2 Flat Washer, 3/8" x 1-1/4"
82 43063 3 Hex Bolt, 5/16-18 x 1" 82 43063 3 Hex Bolt, 5/16-18 x 1"
83 43054 3 Hex Bolt, 3/8-16 x 2" 83 43054 3 Hex Bolt, 3/8-16 x 2"
84 43432 2 Hex Bolt, 3/8-16 x 2-1/2" 84 43432 2 Hex Bolt, 3/8-16 x 2-1/2"
85 24571 1 Spacer 85 24571 1 Spacer
86 46963 2 Chain, Tensioning 86 46963 2 Chain, Tensioning
87 43343 4 Hair Cotter Pin, 3/32" x 2-5/16" 87 43343 4 Hair Cotter Pin, 3/32" x 2-5/16"
88 43055 2 Hair Cotter Pin, 3/32" #3 88 43055 2 Hair Cotter Pin, 3/32" #3
89 46959 2 Spring 89 46959 2 Spring
90 49392 1 V-Belt, Auger 90 49392 1 V-Belt, Auger
91 48569 1 V-Belt, Drive 91 48569 1 V-Belt, Drive
92 24295 1 Clutch & Pulley Frame 92 24295 1 Clutch & Pulley Frame 92 24295 1 Clutch & Pulley Frame
93 731-0851A 3 Chute Keeper 93 731-0851A 3 Chute Keeper
94 1643-60 1 Plastic Grip 94 1643-60 1 Plastic Grip
95 24482 1 Anti-Rotation Bracket 95 24482 1 Anti-Rotation Bracket
96 43661 6 Hex Bolt, 1/4-20 x 1" 96 43661 6 Hex Bolt, 1/4-20 x 1"
97 43088 6 Flat Washer, 1/4" 97 43088 6 Flat Washer, 1/4"
98 43182 1 Hex Bolt, 5/16-18 x 3/4" 98 43182 1 Hex Bolt, 5/16-18 x 3/4"
99 43083 2 Hex Nut, 5/16-18 Thd. 99 43083 2 Hex Nut, 5/16-18 Thd.
100 48106 2 Shoulder Bolt, 3/8-16 x 5/8" 100 48106 2 Shoulder Bolt, 3/8-16 x 5/8"
101 43038 2 Pivot Lock Pin 101 43038 2 Pivot Lock Pin 101 43038 2 Pivot Lock Pin
102 710-0891 2 Shear Bolt, 5/16-18 x 1-3/4" 102 710-0891 2 Shear Bolt, 5/16-18 x 1-3/4" 102 710-0891 2 Shear Bolt, 5/16-18 x 1-3/4"
103 738-0492 1 Shaft, Spiral Axle 103 738-0492 1 Shaft, Spiral Axle 103 738-0492 1 Shaft, Spiral Axle
104 714-0135 1 Woodruff Key, 1/4" x 3/4" 104 714-0135 1 Woodruff Key, 1/4" x 3/4" 104 714-0135 1 Woodruff Key, 1/4" x 3/4"
105 741-0494 4 Flange Bushing 105 741-0494 4 Flange Bushing 105 741-0494 4 Flange Bushing
106 736-0250 6 Flat Washer, 1" x 1-3/4" 106 736-0250 6 Flat Washer, 1" x 1-3/4" 106 736-0250 6 Flat Washer, 1" x 1-3/4"
107 741-0192 2 Flange Bearing W/Flats 107 741-0192 2 Flange Bearing W/Flats 107 741-0192 2 Flange Bearing W/Flats
108 46703 6 Bolt, Self Thd. 5/16-18 x 3/4" 108 46703 6 Bolt, Self Thd. 5/16-18 x 3/4" 108 46703 6 Bolt, Self Thd. 5/16-18 x 3/4"
109 63572 1 Hang er Bracket Assembly, R.H. 109 63572 1 Hang er Bracket Assembly, R.H.
110 63571 1 Hanger Bracket Assembly, L.H. 110 63571 1 Hanger Bracket Assembly, L.H. 110 63571 1 Hanger Bracket Assembly, L.H.
111 25301 2 Frame Bracket 111 25301 2 Frame Bracket 111 25301 2 Frame Bracket
112 23625 8 Spacer 112 23625 8 Spacer 112 23625 8 Spacer
113 64943 1 Hanger Bracket, L.H. (54") 113 64943 1 Hanger Bracket, L.H. (54") 113 64943 1 Hanger Bracket, L.H. (54")
114 64944 1 Hanger Bracket, R.H. (54") 114 64944 1 Hanger Bracket, R.H. (54") 114 64944 1 Hanger Bracket, R.H. (54")
115 43087 4 Hex Bolt, 3/8-16 x 1-1/4" 115 43087 4 Hex Bolt, 3/8-16 x 1-1/4" 115 43087 4 Hex Bolt, 3/8-16 x 1-1/4"
116 41576 1 Hex Bolt, 3/8-16 x 1-3/4" 116 41576 1 Hex Bolt, 3/8-16 x 1-3/4" 116 41576 1 Hex Bolt, 3/8-16 x 1-3/4"
49788 1 Own er's Manual 49788 1 Own er's Manual
REF. PART QTY. DE SCRIP TION
59 784-5149 1 U-Joint
60 43850 2 Roll Pin, 1/8" x 5/8"
61 43070 10 Flat Washer, 3/8"
62 24300 1 Chute Crank Bracket, Rear
63 24299 1 Chute Crank Bracket, Front
64 64504 1 Idler Arm Assembly
65 24286 1 Pivot Spacer
66 63762 1 Idler Bracket Assembly
67 24472 1 Pivot Spacer
68 48883 2 Flat Pulley
69 47044 1 V-Idler Pulley, 4"
70 47064 1 V-Pulley, 5.9"
71 48102 1 V-Pulley, 10"
72 738-0680 1 Shaft
73 750-0456 1 Spacer
74 750-0660 1 Spacer
75 714-0161 2 Key
76 741-0919 2 Ball Bearing
77 08253B 1 Bearing Housing
78 15296A 1 Bearing Housing, Open
79 14088B 1 Spindle Spacer
80 44377 2 Hex Bolt, 3/8-24 x 1"
81 736-0247 2 Flat Washer, 3/8" x 1-1/4"
82 43063 3 Hex Bolt, 5/16-18 x 1"
83 43054 3 Hex Bolt, 3/8-16 x 2"
84 43432 2 Hex Bolt, 3/8-16 x 2-1/2"
85 24571 1 Spacer
86 46963 2 Chain, Tensioning
87 43343 4 Hair Cotter Pin, 3/32" x 2-5/16"
88 43055 2 Hair Cotter Pin, 3/32" #3
89 46959 2 Spring
90 49392 1 V-Belt, Auger
91 48569 1 V-Belt, Drive
92 24295 1 Clutch & Pulley Frame
93 731-0851A 3 Chute Keeper
94 1643-60 1 Plastic Grip
95 24482 1 Anti-Rotation Bracket
96 43661 6 Hex Bolt, 1/4-20 x 1"
97 43088 6 Flat Washer, 1/4"
98 43182 1 Hex Bolt, 5/16-18 x 3/4"
99 43083 2 Hex Nut, 5/16-18 Thd.
100 48106 2 Shoulder Bolt, 3/8-16 x 5/8"
101 43038 2 Pivot Lock Pin
102 710-0891 2 Shear Bolt, 5/16-18 x 1-3/4"
103 738-0492 1 Shaft, Spiral Axle
104 714-0135 1 Woodruff Key, 1/4" x 3/4"
105 741-0494 4 Flange Bushing
106 736-0250 6 Flat Washer, 1" x 1-3/4"
107 741-0192 2 Flange Bearing W/Flats
108 46703 6 Bolt, Self Thd. 5/16-18 x 3/4"
109 63572 1 Hang er Bracket Assembly, R.H.
110 63571 1 Hanger Bracket Assembly, L.H.
111 25301 2 Frame Bracket
112 23625 8 Spacer
113 64943 1 Hanger Bracket, L.H. (54")
114 64944 1 Hanger Bracket, R.H. (54")
115 43087 4 Hex Bolt, 3/8-16 x 1-1/4"
116 41576 1 Hex Bolt, 3/8-16 x 1-3/4"
49788 1 Own er's Manual
REF. PART QTY. DESCRIPTION
NO. NO.
1 63576 1 Housing Assembly
2 64517 1 Impeller Assembly
3 47368 2 Spring Pin, 5/16" x 1-3/4"
4 47369 2 Spring Pin, 3/16" x 1-3/4"
5 63772 1 Spiral Assembly, R.H.
6 63771 1 Spiral Assembly, L.H. (Not Shown)
7 618-04045 1 Auger Gear Assembly
8 24308 1 Gear Housing Support Plate
9 784-5076 1 Gear Housing Support Bracket
10 46703 1 Bolt, Self Thd., 5/16-18 x 3/4"
11 R19111116 7 Flat Washer, 11/32" x 11/16"
12 43063 3 Hex Bolt, 5/16-18 x 1"
13 43064 38 Hex Lock Nut, 5/16-18 Thd.
14 43086 30 Lockwasher, 5/16"
15 24913 1 Bearing Offset Bracket
16 48593 1 Spacer
17 47598 6 Flanged Lock Nut, 1/4-20 Thd.
18 24942 1 Belt Keeper Bracket
19 24941 1 Belt Cover
20 47810 12 Nylock Nut, 5/16-18
21 47044 2 V-Pulley, Idler
22 05845B 2 Bearing Housing
23 24911 1 Idler Bracket, L.H.
24 24910 1 Idler Bracket, R.H.
25 24912 1 Cross Tie Bracket
26 48595 1 Key, 3/16" x 3/4"
27 43353 2 Lockwasher, 1/2"
28 43262 2 Hex Lock Nut, 1/2-13 Thd.
29 711-0242 2 Spacer
30 44917 1 Palnut, 3/8"
31 24309 1 Wear Plate
32 43080 20 Carriage Bolts, 5/16-18 x 3/4"
33 43081 16 Flat Washer, 5/16"
34 24279 2 Skid Shoe
35 G586868 2 Leveling Shoe
36 24481 2 Skid Shoe Bracket
37 43001 8 Hex Bolt, 3/8-16 x 1"
38 43003 18 Lockwasher, 3/8"
39 43082 17 Hex Lock Nut, 3/8"
40 44326 10 Carriage Bolt, 5/16-18 x 1"
41 48570 1 Bearing, Self Aligning
42 48572 1 Pulley, 9"
43 710-0696 1 Hex Bolt, 3/8-24 x 7/8"
44 736-0247 1 Flat Washer, 3/8" x 1-1/4"
45 731-1696 1 Discharge Chute Adapter
46 784-5711 1 Chute Bracket, 6"
47 48015 5 Nylon Washer, 5/8"
48 731-0903D 1 Lower Discharge Chute
49 731-0846C 1 Upper Discharge Chute
51 731-1313C 1 Cable Guide
52 784-5594 1 Cable Bracket
53 746-0928 1 Chute Control Cable
54 746-0929 1 Chute Control Cable w/Clip
55 43085 1 Hex Bolt, 5/16-18 x 1-1/2"
56 710-0896 1 Hex Screw, 1/4-14 x 5/8"
57 741-0475 2 Plastic Bushing, 3/8"
58 684-0061 1 Chute Crank Assembly
