Bridge Filters
The Bridge Filters allows you to enable, add, edit, or delete the filter rules. When bridge filtering is
enabled, each frame is examined against every defined filter rule in sequence. When a match is found,
the appropriate filtering action (allow or deny) is performed. Up to 20 filter rules are supported with
bridge filtering.
Bridge Filters
To configure Bridge Filters:
1. From the Advanced Menu, select Application > Bridge Filters. This opens the Bridge Filters
page.
2. Check Enable Bridge Filters.
3. To add a rule, enter Src MAC address, Src Port, Dest MAC address, Dest Port, Protocol,
and Mode, then click Add.
Note: You can also edit a rule that you created using the Edit checkbox. You can delete using
Delete.
4. Click Submit to temporarily activate the settings.
5. To make changes permanent, click Save Settings.
