The IGMP Proxy page allows you to enable multicast on available WAN and LAN connections. You can
configure the WAN or LAN interface as one of the following:
Upstream The interface that IGMP requests from hosts are sent to the multicast router.
Downstream The interface data from the multicast router are sent to hosts in the multicast
group database.
Ignore No IGMP request nor data multicast are forwarded.
You can perform one of the two options:
1. Configure one or more WAN interface as the upstream interface.
2. Configure one or more LAN interface as the upstream interface.
To configure the IGMP Proxy:
1. From
the
Advanced Menu, select Application > IGMP Proxy.
2. Check
Enable IGMP Proxy.
3. Configure the listed interfaces.
4. Click
Submit to temporarily apply the settings.
5. To make changes permanent, click Save Settings.
