Seagate U4 ST36421A - Manual (Page 28)

20 U4 Family Product Manual, Rev. D
1.00 ± 0.028
( 25.4 ± 0.7)
3.72 ± 0.03
(94.5 ± 0.8
)
4.00 ± 0.02
(101.6 ± 0 . 5)
3.750 ± 0.010
(95.25 ± 0 . 25)
5.75 ± 0.03
( 146.1 ± 0.8 )
4.000 ± 0.010
( 101.60 ± 0.25 )
3X.250 ± . 015
(6.35 ± 0.38)
(both sides)
2.23 ± 0.03
(56.6 ± 0.8
)
0.230 ± 0.015
(5.84 ± 0.38 )
0.180 ± 0.015
(4.57 ± 0.38)
2.362 ± 0.010
( 59.99 ± 0.25 )
1.750 ± 0.010
(44.45 ± 0 . 25)
3X 6-32 UNC-2B
max. insertion depth
0.14 (3.6) both sides
4X 6-32 UNC-2B
max. insertion
depth 0.22 (5.6)
2.375 +0.030, –0.005
(60.33 +0.76, –0.13)
0.125 +0.030, –0.005
(3.18 +0.76, –0.13)
0.630 +0.030, –0.005
(16.00 +0.76, –0.13)
Note: Dimensions are shown in inches (mm).
Figure 3. Mounting dimensions—top, side and end view
