Page 5
5
TP 400-3542-00-AT-SMA
Auger Housing Group - 42”
1
1704446
1
GUARD & SUPPORT ASSEMBLY
2
1960001
3
SCREW, Hex Washer Head, Plastite, #10-14 x 5/8
3
1931333
11
CARRIAGE BOLT, 5/16-18 x 3/4
4
960210
1
WASHER, Nylon
5
1919326
1
WASHER, 5/17, Black
6
1919438
1
NUT, Hex Lock ESNA, 5/16-18
7
1723948
1
CHUTE & DEFLECTOR ASSEMBLY
8
1702219
3
SPACER
9
1921319
6
WASHER, 1/4, Black
10
1960126
4
NUT, Push, Black
11
1611945
1
ROD
12
1611939
1
SPRING, Compression
13
1700048
1
BOOT, Water
14
1724568
1
CABLE & KNOB ASSEMBLY
(Includes Ref. Nos. 13, 22, 23, 24, 25, 27 & 28)
15
1916622
2
NUT, Hex, 1/4-20
16
1916964
3
LOCKWASHER, 1/4, Black
17
1960151
2
WASHER, 1/4, Black
18
1668344
1
PIN, Flat Head Drilled
19
1721590
1
BRACKET, Mounting
20
1924009
3
CAPSCREW, Hex Head, 1/4-20 x 7/8, Black
21
1960221
1
CLIP, Hair Pin
22
1960600
1
SCREW, Pan Head, #8-32 x 11/16
23
1719138
1
HANDLE, cable
24
1717477
1
GEAR, Chute
25
1666613
3
HOLD DOWN, Chute, Nylon
26
1705920
1
BRACKET, "L"
27
1715787
2
CUTTER, Drift
28
1921332
4
CAPSCREW, Hex Head, 5/16-18 x 3/4, Black
29
1724210
1
SWITCH, Rocker, Chute Rotator
30
1723117
1
HARNESS ASSEMBLY, Chute Rotator
31
1716987
1
HARNESS ASSEMBLY, Power Outlet
32
1722735
1
HARNESS ASSEMBLY, Spout Rotator
33
1923358
1
NUT, Hex Center Lock, 1/4-20, Black
34
1717480
1
PINION
35
1717591
1
ROD & BAR ASSEMBLY
36
1917356
7
LOCKWASHER, 5/16, Black
37
1917372
4
NUT, Hex, 5/16-18, Black
38
1723930
1
COVER, Pinion
39
1925003
2
CAPSCREW, Hex Washer Head, 1/4-20 x 1/2
40
1715885
1
MOTOR, Electric
41
172279
2
FLANGE, Bearing
42
173934
2
BEARING, Cartridge
43
172278
2
FLANGE, Bearing
44
1923325
6
CAPSCREW, Hex Head, 5/16-18 x 7/8, Black
45
1916950
4
NUT, Hex, 3/8-16, Black
46
1916965
4
LOCKWASHER, 3/8
47
1924940
4
WASHER, 3/8, Black
48
1723916
2
SKID PLATE ASSEMBLY
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1694238
Two-Stage Snowthrower, 42”
