11
CHAIN CASE, L. H. FENDER
ITEM PART NO. DESCRIPTION
1 5-2683 ASSEMBLY, Chain Case (Includes Items 2 Thru 13,
& 15, 16, 31, 30)
2 4-1136 CASE, Sprocket (Weldment)
3 2-8761 GASKET, Case Cover
4 1-1121 WASHER, Belleville
5 1-0756 BEARING, Ball (2)
6 1-8963 SPROCKET & SHAFT
7 1-0614 KEY, 1/8 x 5/8" Woodruff
8 3-9778 COVER, Chain Case
9 1-0942 BEARING, Needle (2)
10 1-1086 WASHER, Nylon Thrust (2)
11 4-0355 HUB & SPROCKET (Weldment)
12 1-0941 CHAIN
13 9-0307 SCREW, #10-24 x 5/8" Hex Washer Self-Tap (10)
14 1-1024 PLUG, Oil Fill & Check
15 2-2785 ROLLER
16 1-0776 RING, 1/2” External Retaining
17 5-9183 ASSEMBLY, Left Hand Fender (Includes items 18 & 19)
18 3-7285 FENDER, Left Hand
19 5-2827 ASSEMBLY, Axle Bearing (Incl. items 20 thru 23)
20 7-4184 BEARING, Left Hand Fender
21 1-3324 FITTING, Lube (for 3/16” diameter hole)
22 7-4500 SEAL, Dust/Grease Axle
23 7-4182 BEARING, 3/4” I. D. DX (2)
24 1-2271 WASHER, Shim (As Required)
25 1-1070 ROD, Cross-Tie
26 1-2332 CLAMP, Boot (2)
27 1-7084 BOOT, Oil Seal
28 1-1071 WASHER, Thrust Nylon
29 1-1072 WASHER, Thrust
30 9-1505 NUT, 5/8-18 Hex Nyloc
31 1-0969 NUT, 5/16-24 Hex Flange Lock
32 1-9260 O-RING (2)
33 2-7981 WASHER, Wave
-- 6-1017 GREASE , SNAPPER Transmission (4 oz. Required)
-- 5-1451 ASSEMBLY, Left Hand Fender (Includes Left Hand Fender
P.N. 3-7958 & Ball Bearing P.N. 1-4624)
NOTE: See Pages 12 &13 For Illustration Of Brake Lever Assembly And Related Parts.
42” MODEL R. E. RIDER SERIES 22 MANUAL No. 06130
