Snapper 421622BVE - Manual

Parts Manual for
REAR ENGINE RIDER
42” MOWER
SERIES 22
MODELS
421622BVE
CONTENTS
DESCRIPTION PAGE(S) DESCRIPTION PAGE(S)
WHEELS- TIRES ................................................................. 2-3
FRONT END, STEERING. ................................................... 4-5
MAIN CASE.......................................................................... 6-7
DIFFERENTIAL, R. H. FENDER .......................................... 8-9
CHAIN CASE, L.H. FENDER ............................................10-11
SMOOTH CLUTCH ASSEMBLY ......................................12-13
RAILS, LIFT ARMS, CAM LIFT ........................................14-15
CUTTING DECK, DEFLECTOR........................................16-19
DECK COVER, BELTS, BLADE BRAKES.......................20-21 SPINDLE ASSEMBLY........................................................... 22
DRIVE DISC ASSEMBLY...................................................... 23
FUEL TANK & OPERATOR’S SEAT .................................... 24
EXHAUST MUFFLER, ENGINE ............................................ 24
THROTTLE CONTROL ......................................................... 25
ELECTRICAL SYSTEM....................................................26-27
WIRING SCHEMATIC28
DECALS .............................................................................29-31
ACCESSORIES & ATTACHMENTS ..................................... 36
COPYRIGHT © 2002
SNAPPER INC.
ALL RIGHTS RESERVED
(Rev. 1, 06/30/02) MANUAL No. 06130
