Front View of the VCR
Rear View of the VCR
The following illustrations represent precautions.
The lightning bolt is a warning sign alerting you to dangerous voltage inside the product.
DO NOT OPEN THE VCR. Refer to service personnel.
H H 5 ° C
40 ° C 10% 75%
THIS DEVICE IS NOT FOR USE IN INDUSTRIAL
ENVIRONMENTS
Safety Instructions
Do NOT expose the VCR to
extreme temperature condi-
tions (below 5°C and above
40°C) or to extreme humidity
conditions (less than 10% and
more than 75%). Do NOT expose the VCR to
direct sunlight. Do NOT expose the VCR to
any liquids.
Do NOT place any objects on
the VCR or remote control. During a storm and/or light-
ning, unplug the VCR from the
mains socket and aerial. If the remote control is not
used for a long period of time,
remove the batteries and store
it in a cool, dry place.
TV
AV2 (SATELLITE) IN
AV1 (EURO AV)
R/D
L/G
AUDIO
OUT/SORTIE
AV2 (SATELLITE) IN SCART
(EURO-21) SOCKET
AV1 (EURO AV) IN/OUT
SCART (EURO-21) SOCKET
AERIAL IN
CONNECTOR
OUT TO TV
CONNECTOR RCA AUDIO L, R OUTPUT
SOCKETS
VIDEO CASSETTE
COMPARTMENT
PLAY
BUTTON
RECORD
BUTTON
EJECT
BUTTON
F.F
BUTTON
PROGRAMME SELECTION
BUTTONS
REW
BUTTON
REC STOP PROG
EJECT STANDBY/ON
REW F.F PLAY
STANDBY/ON
BUTTON
STOP
BUTTON
AUX
VIDEO L - AUDIO - R
STANDBY/ON
EJECT
PROG REC II P/S
RE W F.F
STOP
VIDEO CASSETTE
COMPARTMENT
STOP
BUTTON
REW
BUTTON F.F
BUTTON
RECORD
BUTTON EJECT
BUTTON INFRARED REMOTE
SENSOR
PROGRAM SELECTION
BUTTONS
PAUSE/STILL
BUTTON PLAY
BUTTON
STANDBY/ON
BUTTON
AUX VIDEO INPUT
SOCKET
AUX AUDIO L, R
INPUT SOCKETS
(SV-645B)
(SV-643B/SV-640B)
