18
TECHNICAL SPECIFICATIONS
MODEL
PH1-14R-03
(Reference#: KY-36) PH1-12R-03
(Reference#: KY-34)
Cooling Capacity 14,000 BTU/Hr 12,000 BTU/Hr
Heating Capacity 14,200 BTU/Hr 12,200 BTU/Hr
Dehumidifying Capacity 65 pts/day 63 pts/day
Cooling 1390 W 1340 W
Power Consumption
Heating 1180 W 1090 W
Air Flow Volume 328CFM 280CFM
Power Source 115 V / 60 HZ 115 V / 60 HZ
Cooling 12 A 11.7 A
Rated Current
Heating 9.8 A 9.5 A
Sound Pressure Level <49 db(A) <49 db(A)
Weight 80 lbs 80 lbs
Dimensions 14.4 W x 22.4 D x 30.5 H inches 14.4 W x 22.4 D x 30.5 H inches
Refrigerant R22 R22
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL
ARE THE PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT
CONDUCTED INDEPENDENT TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED
HEREWITHIN.
