Specifications
LCD Projector
PG-A10X
NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/PAL-60/SECAM/
DTV480I/DTV480P/DTV540P/DTV580I/DTV580P/DTV720P/DTV1035I/DTV1080I
LCD panel
× 3, RGB optical shutter method
Panel size: 0.79" (20.0 mm) (12 [H] × 16 [W] mm)
No. of dots: 786,432 dots (1,024 [H]
× 768 [V])
1–1.2 × zoom lens, F1.9–2.2, f = 26–31 mm
SHP 165 W lamp
15-pin mini D-sub connector
Y: 1.0 Vp-p, sync negative, 75
Ω terminated
P
B
: 0.7 Vp-p, 75
Ω terminated
P
R
: 0.7 Vp-p, 75
Ω terminated
700 TV lines (DTV720P)
15-pin mini D-sub connector
RGB separate/sync on green type analog input: 0–0.7 Vp-p, positive, 75
Ω terminated
HORIZONTAL SYNC. SIGNAL: TTL level (positive/negative)
VERTICAL SYNC. SIGNAL: Same as above
4-pin mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75
Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75
Ω terminated
RCA connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω
terminated
9-pin mini DIN connector
12–108 MHz
43–85 Hz
15–70 kHz
ø3.5 mm minijack: AUDIO, 0.5 Vrms, more than 47 k
Ω (stereo)
1.0 W (monaural)
2.8 cm round
× 1
AC 100–240 V
2.4 A
50/60 Hz
240 W (Standard mode)/190 W (Eco mode) with AC 100 V
226 W (Standard mode)/182 W (Eco mode) with AC 240 V
5 W (AC 100 V) – 8 W (AC 240 V)
900 BTU/hour (Standard mode)/710 BTU/hour (Eco mode) with AC 100 V
850 BTU/hour (Standard mode)/680 BTU/hour (Eco mode) with AC 240 V
41°F to 95°F (+5°C to +35°C)
–4°F to 140°F (–20°C to +60°C)
Plastic
38 kHz
11
45 / 64 "
Ч 3
13 / 64 "
Ч 9
1 / 32 " (297 (W)
× 81 (H) × 229 (D) mm) (main body only)
11 45 /
64
" Ч 3
33 /
64
" Ч 9
1 /
32
" (297 (W) × 89 (H) × 229 (D) mm) (including adjustment foot
and projecting parts)
6.4 lbs. (2.9 kg)
Remote control, Two R-6 batteries, Power cord for U.S., Canada etc. (6', 1.8 m), Power cord
for Europe, except U.K. (6', 1.8 m), Power cord for U.K., Hong Kong and Singapore (6', 1.8
m), Power cord for Australia, New Zealand and Oceania (6', 1.8 m), RGB cable (9'10",
3.0 m), DIN-D-sub RS-232C adaptor (5
57 /
64
", 15 cm), Carrying case, Lens cap (attached),
Extra air filter, Projector manual and technical reference CD-ROM, “QUICK GUIDE” label,
Operation manual
Lamp unit (Lamp/cage module) (BQC-PGA10X//1), Remote control (RRMCGA138WJSA),
Two R-6 batteries (“AA” size, UM/SUM-3, HP-7, or similar), Power cord for U.S., Canada etc.
(QACCDA016WJPZ), Power cord for Europe, except U.K. (QACCVA006WJPZ), Power cord
for U.K., Hong Kong and Singapore (QACCBA015WJPZ), Power cord for Australia, New
Zealand and Oceania (QACCLA005WJPZ), RGB cable (QCNWGA012WJPZ), DIN-D-sub
RS-232C adaptor (QCNWGA015WJPZ), Carrying case (GCASNA006WJSA), Lens cap
(CCAPHA007WJ01), Air filter (PFILDA008WJZZ), Projector manual and technical reference
CD-ROM (UDSKAA022WJZZ), “QUICK GUIDE” label (TLABZA191WJZZ), Operation manual
(TINS-A505WJZZ)
Product type
Model
Video system
Display method
LCD panel
Standard lens
Projection lamp
Component input signal
(INPUT1)
Horizontal resolution
Computer RGB input signal
(INPUT 1)
S-video input signal
(INPUT 2)
Video input signal
(INPUT 3)
Computer control signal (RS-232C)
Pixel clock
Vertical frequency
Horizontal frequency
Audio input signal
Audio output
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power consumption
(standby)
Heat dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
This SHARP projector uses an LCD (Liquid Crystal Display)
panel. This very sophisticated panel contains 786,432 pix-
els (
× RGB) TFTs (Thin Film Transistors). As with any high
technology electronic equipment such as large screen TVs,
video systems and video cameras, there are certain accept-
able tolerances that the equipment must conform to.
This unit has some inactive pixels within acceptable toler-
ances which may result in inactive dots on the picture
screen. This will not affect the picture quality or the life ex-
pectancy of the unit.
Specifications are subject to change without notice.
