13
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
SUPERIOR ® DIRECT-VENT GAS FIREPLACES • MODELS SLDVT-30/35/40/45 • CARE AND OPERATION INSTRUCTIONS
SLDVT-30 AND SLDVT-35 LOG PLACEMENT
Figure 9
Step 2
Step 3
Step 4
3
Left Rear Brackets
Step 1
Align hole at the bottom of left front log (1) over the left front
brackets and the right front log over the right front brackets.
2
Align the hole at the bottom of log (4) over
the "Nub" of log (2) as shown.
4
2 1
Right Rear Bracket
Rockwool
(Do Not Place Rockwool Over Burner Slots)
1
Right Front Brackets Left Front Brackets
3
1
Right Front Log "Nub"
2
4
2
Log
Number Description
1 Left Front Log
2 Right Front Log
3 Left Rear Log
4 Right Rear Log
Catalog Number for the entire
log set: H7244
Position on the left
rear log brackets
