9. Install the Bumpers and Screw Covers
Install the Center Jamb Bumper
Run a #8 x 3/8
″ self drilling screw through a bumper insert.
Insert a screw into the pre-drilled hole in the center jamb and tighten.
Place a bumper on each bumper insert in the vertical position.
Rotate the bumper so the Sterling logo is upright.
Install the Screw Covers
Install a screw cover over each of the eight exposed screw heads on the wall jamb and column
assembly.
Bottom Track
Screw
Top Track
Bumper
Insert
Wall
Jamb
Inside of Bath
Screw
Outside of Bath
#8 x 3/8"
Self-Drilling Screw
Screw Cover
1035946-2-C 10 Sterling
