ASSEMBLY
Remove all the parts from the box. Please check to make sure the
following items are included with the main unit in the carton:
(1) Operating instructions
(2) Platter
(3) Slip
mat
(4) Counterweight
(5) 45-rpm
adapter
(6) Headshell
(7) AC cord
(8) Connecting cord
(9) Cartridge
CONNECTIONS
1. Connect the power cord to the auxiliary power outlet on the rear panel
of your amplifier or receiver or to a household AC outlet.
2. Connect the unit output terminals to the PHONO jack of your amplifier
or receiver.
Output terminals Amplifier (Receiver)
L White) L Channel
R (Red) R Channel
GND (Spade) GND
NOTE:
Be sure to connect the ground terminal firmly to the amplifier or receiver.
If this connection is not made or is loose, a power source "HUM" will
result.
TONE ARM AND CARTRIDGE SETTINGS
The major cause of problems in sound and skipping on the vinyl is the
lack of proper set up of the needle and turntable adjustments. The needle
is designed to operate at a specific angle to the vinyl. The str8-90 has
several adjustments to correctly position the
needle to the vinyl.
The first adjustment is the correct installation of the cartridge.
Your cartridge is to be mounted into the headshell as pre the mounting
instructions included with the cartridge. The Stanton 500,680 and 890
series of cartridges require the use of the two screw mounting into the
headshell. For you convenience, some of these products can be
purchased already mounted and pre-adjusted from your local Stanton
dealer. If you are using these 1/2” mounted products with a headshell in a
mobile application or you are doing heavy scratching, May want to use an
extra shell weight. The Master series of products (Trackmaster,
Groovemaster, etc.) are designed with their own mounting that eliminates
the need for a separate headshell and the wiring to the cartridge.
The body of the cartridge should be parallel with the centerline of the
headshell-tone arm, when viewed from the front to the back.
The second adjustment is at the installation of the
cartridge-head-shell assembly into the tone arm tube lock. Holding
the tone arm tube in one hand, insert the cartridge-headshell into the tube
lock with the other hand. Turn the lock ring clockwise (when viewed from
the rear) until the headshell is locked tightly into the tone arm. Remove
the needle protector from the cartridge and place the needle on record.
View the needle from the front and insure that the needle is perpendicular
to the record surface. If some adjustment is needed, simply loosen the
lock ring and rotate the cartridge-headshell until the needle is
perpendicular to the record surface. Then re-tighten the lock ring.
The third adjustment is the needle (or stylus) pressure. Start with the
cartridge-headshell assembly mounted into the tone arm. Remove any
needle protectors provided. With tone arm free, adjust the tone arm
counterweight by rotating the rear section until the tone arm floats in a
balanced condition above the record or mat. Do not allow the needle to
drop onto the mat or the turntable platter during this adjustment. You
might damage the needle tip. Now, carefully hold the tone arm in one
hand while rotating the numbered ring on the front of the counter-weight
with the other hand to the “0” setting. Next, without touching the
numbered ring, Rotate the rear counterweight until the desired needle
pressure reading is next to the line on top of the tone arm tube, See the
instructions. Included with your cartridge for proper settings.
The fourth and last adjustment is that of the tone arm height. This
will set the tone arm pivot and needle relation with the vinyl. Unlock the
tone arm base located in the base of pivot assembly. Rotate the height
adjust ring in the pivot base to read the correct setting for the height
adjust ring in the pivot base to read the correct setting for the height of
the cartridge that you are using. Check the cartridge/arm height table for
the correct setting. Be certain to re-lock the pivot base when adjustment
is completed.
