Samsung ML-1430 - Manual (Page 52)

4.13 P
RINT
M
EDIA
2
Push the output lever down.
1
Load print media in the input tray with
print side up, short edge first .
Adjust the guide to fit the width of the
media.
3
Configure the paper source, type in the
printer driver’s properties (see page
5.3 ) and print.
4
Press Demo to start feeding.
Postcards, 3” X 5” index cards can be printed with the Samsung ML-1430 Series printer.
Guidelines
• Insert the short-edge first into the input tray . To print in landscape mode, make this
selection through the software. Inserting paper long-edge first may cause a paper jam.
• Do not print on card stock that is too small or too large. The minimum size is 76 X 127
mm (3” X 5”) for the manual input tray and 95 X 127 mm (3.8” X 5”) for the automatic
input tray, and the maximum size is 216 X 356 mm (8.5” X 14”).
• Set margins at least 6.4 mm (0.25 in.) away from the edges of the media in the software
application.
Printing on Card Stocks
