1-1
The VP1 bracket arms are adjustable to accomodate projectors with hole patterns as large as 16.63 inches (422.5 mm) square.
Loosen the arm positioning screws to adjust the bracket to fi t your projector.
16.13 in
409.8 mm
16.63 in
422.5 mm
8.97 in
228.0 mm
