Sanyo CH0922 - Manual

DIMENSIONAL DATA
Indoor Unit: KHS0921, KHS0922
Wireless remote
control unit
31-1/2
7-3/32
7-11/64 17-23/32
Rear panel
(center point
of gravity)
6-23/32
13
-1
9/
32
1-
49
/6
4
3-
3/
4
15
/3
2 1-
49
/6
4
1-3/8
5-1/2
1-49/64
Center of
tubing hole
(for right
rear)
O.D. 3/8" wide tubing
O.D. 1/4" narrow tubing
Drain hose O.D. 23/32
1-
5/
8
6-
7/
64
2-13/64 19/32
Outdoor Unit: CH0921, CH0922
4 15/32 dia. hole
Air intake
Air discharge
23-15/16 2-3/8
29-17/32
Air
intake
Check port
2-1/4 1-3/16 9-27/32
20
-7
/8
21
/3
2
2-
23
/3
2
2-
3/
8
1/4" narrow tubing
service valve
3/8" wide tubing
service valve
10
-2
3/
32
11
-7
/8
WARRANTY
SANYO products are warranted against defects in materials and workmanship for the
period below;
LABOR PARTS
Compressor 30 Days 5 Years
Other Components N/A 1 Year
Because of a policy of continuous product improvements, SANYO reserves the right
to change specifications and design without notice.
Full specific warranty rights, conditions, exclusions and obligations are specified in the
warranty packed with each products.
