AppendixC-E.frame Black #1

109

Appendix C: Interface Pin Outs / Annexe C: Disposition des broches pour interfaces
Anhang C: Interface-Pin-Belegung / Appendice C: Uscite a terminale interfaccia

Optional Serial Interface

Pin

Name

Function

1

GND

Printer chassis ground

2

TXD

Data from printer

3

RXD

Data to printer

4

RTS

Always low

5

CTS

Low when computer is ready to send data. Printer ignores this signal.

6

Not connected.

7

GND

Signal ground

8 - 10

Not connected.

11

RCH

Printer sets line low when ready to receive data. Same signal as Pin 20.

12 - 19

Not connected.

20

DTR

Printer sets line low when ready to receive data.

21 - 25

Not connected.

Parallel Interface

Pin

Name

Function

1

STROBE

Goes low for

0.5

µ

s when active.

2

DATA0

High when active.

3

DATA1

High when active.

4

DATA2

High when active.

5

DATA3

High when active.

6

DATA4

High when active.

7

DATA5

High when active.

8

DATA6

High when active.

9

DATA7

High when active.

10

ACK

10

µ

s low to acknowledge receipt of data.

11

BUSY

Printer sets line low when ready to receive data.

12

PAPER

High when paper runs out. Can be disabled with the User Setup Utility.

13

SELECT

High when printer is on-line.

14

AFXT

Normally high.

15

Not connected.

16

SIGNAL GND

Signal ground

17

CHASSIS

Chassis ground (isolated from signal ground)

18

+5V

+5V DC output from printer

19 - 30

GND

Twisted pair ground return

31

RESET

Printer is reset when this signal goes low.

32

ERROR

Low when printing cannot continue due to error.

33

EXT GND

External ground

34 - 35

Not connected

36

SELECT IN

Normally low.
