Setting the jumper pin
Setting the jumper pin
Before installing the Samsung hard disk drive, the jumpers must be set to match the configuration of your computer system.
Refer to the following diagram for instructions on setting the jumper pins.
English
3
Master
Slave
Cable Select
Master
Slave
Cable Select
32GB Clip Configuration
General Configuration
*General configuration setting as "Slave" is "Remove the jumper"
*32GB Clip Configuration "Slave" is set as above
