For Machines Mfg. Since 5/11 14" TURN-X ® Toolroom Lathe
-93-
E L E C T R I C A L
2-Seed Motor Switch
(Both Sides Shown)
Front
View
Rear
View
6 S 4
1 3
T 2 R
5
R1
R1
T1
T1
S1
S1
LOW
LOW
LOW
LOW LOW
LOW
HI
HI
HI
HI
HI
HI
2-Speed Motor Switch
Figure 143. 2-Speed motor switch.
2-Speed Motor
Switch
To Electrical
Cabinet
Page 90
To Spindle Motor
Page 92
