ii Camfire PC Installation and User's Guide
Installation Checklist
Step 1: Install the Camera Boom(s)
To install a single camera boom
1. Mount the camera boom on the wall (page 4).
2. Connect an external power supply, if required (page 9).
3. Connect the camera boom to a computer (page 13).
To install multiple camera booms
1. Mount the camera booms on the wall (page 4).
2. Connect the camera booms to each other (page 7).
3. Connect any external power supplies that may be required (page 9).
4. Connect the first camera boom to a computer (page 13).
Step 2: Install Camfire PC Software and Notebook Software
See page 15.
Step 3: Attach a Capture Slide to each Whiteboard
See page 15.
Step 4: Calibrate the System
To calibrate the system
1. If you have multiple camera booms, reorder and name the whiteboards (page 18).
2. Refine the image alignment (page 19).
