10 Camfire PC Installation and User's Guide
Computer
Location
First Camera Boom Second Camera Boom Third Camera Boom Fourth Camera Boom
Figure 5: External Power Supply Connections
(Computer on the Right Supplies 12W of 12V DC Power to the First Camera Boom)
Second Camera Boom Third Camera Boom Fourth Camera Boom
Computer
Location
First Camera Boom
You may also
connect this
power supply
to the second
or third camera
boom
Figure 6: External Power Supply Connections
(Computer on the Left Cannot Supply 12W of 12V DC Power to the First Camera Boom)
Third Camera Boom Second Camera Boom First Camera Boom Fourth Camera Boom
You may also
connect this
power supply
to the second
or third camera
boom
Computer
Location
Figure 7: External Power Supply Connections
(Computer on the Right Cannot Supply 12W of 12V DC Power to the First Camera Boom)
