16

REVERSING THE DOOR SWING

Read these instructions completely and carefully

12. Disassemble the Door S/W with tools. Be careful

not to scratch.

14. Assemble the each part into the reverse side as

below picture. Assemble the Door S/W as it is.
(Make sure not to insert it upside down)

15. Assemble Freezer Door by fitting Hinge-Low into

the grommet hinge hole. Don't forget to insert
washer with grease.

16. Fix the additional Hinge mid into the door hole.

Door S/W

Door S/W

13. Disassemble the Cap Door S/W, Sleeve and the

screws.

Cap Door S/W

Cap Door S/W

Sleeve

Sleeve

Washer

Washer

Additional
Hinge mid

Additional
Hinge mid

11. Assemble each part by exchanging its into the

reverse side as below picture.
