Part Names
TV (Front)
*OPC: Optical Picture Control
TV (Rear/Side)
*1
*2
*3
*1
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH
U/V)
Volume
buttons
(VOL
k/l)
DIGITAL AUDIO
OUTPUT terminal
INPUT 6 terminal
(HDMI)
INPUT 5 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 5) *4
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT
terminals
AC INPUT
terminal
INPUT 3
terminals
SERVICE
terminal
INPUT 7
terminal
(HDMI)
*1 See page 11 for external equipment connection.
*2 See page 17 for button operations.
*3 See page 8 for connecting the AC cord.
*4 See page 21 for details on the PC Audio Select function.
The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations. •
POWER indicator (See page 12.)
OPC sensor* (See page 18.)
Remote control sensor
