133
TROUBLESHOOTING AND MAINTENANCE
7
MISFEED IN THE UPPER EXIT AREA
(when a job separator tray kit or finisher (MX-FN13) is installed)
If a job separator tray kit or a finisher is installed, a misfeed may occur in the upper exit area.
1 Open the upper right side cover. 2 Gently pull the misfed paper out.
Be careful not to tear the
misfed paper during
removal.
3 Close the upper right side cover.
Make sure that the misfeed message is cleared.
MISFEED IN AN OUTPUT TRAY
(when a finisher (MX-FN13) is installed)
1 Open the front cover.
2 While pressing the lever over to the
left, slide the finisher to the left until it
stops.
Gently slide the finisher
until it stops.
3 Turn roller rotating knob in the
direction of the arrow to remove the
misfed paper.
4 Slide the finisher back to the right.
5 Close the cover.
