BJ5-620 Appendix 70 of 73
806 1 Oil filter SP-10
900 Electrical parts
901 2 Safety switch CAZ15zvrk
902 1 Small control box
903 1 Control panel
904 2 Proximity switch II0297
905 2 Cable for Proximity switch E10200
SXS 2000
Pos. Pc Description/Standard
100 Machine complete
101 1 Standard hopper
102 2 PP-scraper side
103 1 PP-scraper top
104 1 Upper door
105 1 Lower door
106 2 Safety grid side
107 1 Safety grid back
108 1 Safety grid back
109 1 Ram residual chute
200 Screen complete (Hydraulic)
201 1 Screen
202 6 Screen support screws DIN912 – M16x25 – 8.8
203 2 Screen adjusting bolt
204 1 Screen support
205 2 Cylinder for screen support opening Ø63xØ35x155
206 4 Washer DIN125 -A- 13
207 4 Lock washer DIN 127 - 12
300 2 Bearing
301 2 Bearing housing SN236
302 2 Bearing 22236/W33
303 3 Bearing Cover A
304 1 Bearing Cover B
305 0
306 4 Sealing DIN3760 D200 x 230 x 15
307 2 Grease nipple GB1152-89/M8x1
308 2 Sleeve
309 32 Fixing bolt DIN912 – M10x40 – 8.8
310 2 Washer disc
311 2 Fixing bolt DIN912 – M16x50 – 12.9
400 Drive
1 Motor 75 kW 460V/60Hz (right)
1 Motor 75 kW 460V/60Hz (left)
1 Motor 90 kW 460V/60Hz (right)
401
1 Motor 90 kW 460V/60Hz (left)
Gear pulley SPC375-5
402 2
Gear pulley SPC400-6
Gear pulley taper bush TB 3535-48
403 2
Gear pulley taper bush TB 4040-50
404 0
405 10 V-Belt SPC3250
