Specifications
CPD-100ES/100EST
Picture tube
0.25 mm aperture grille pitch
15 inches measured diagonally
90 degree deflection
Viewable image size Approx. 285
×
214 mm (w/h)
(11
1
/
4
×
8
1
/
2
inches)
14.0” viewing image
Logical resolution
Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Physical resolution
Horizontal: Max. 1024 dots
Vertical: Max. 768 lines
Standard image area Approx. 270
×
202 mm (w/h)
(10
3
/
4
×
8 inches)
Deflection frequency Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
AC input voltage/current
100 to 240 V, 50 – 60 Hz, 2 – 1 A
Dimensions
Approx. 368
Ч
392
Ч
389 mm (w/h/d)
(14
1
/
2
Ч
15
1
/
2
Ч
15
3
/
8
inches)
Mass
Approx. 14 kg (30 lb 14 oz)
CPD-200ES/200EST
Picture tube
0.25 mm aperture grille pitch
17 inches measured diagonally
90 degree deflection
Viewable image size Approx. 327
×
243 mm (w/h)
(12
7
/
8
×
9
5
/
8
inches)
16.0” viewing image
Logical resolution
Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Physical resolution
Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Standard image area Approx. 312
×
234 mm (w/h)
(12
9
/
32
×
9
7
/
32
inches)
Deflection frequency Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
AC input voltage/current
100 to 240 V, 50 – 60 Hz, 2 – 1 A
Dimensions
Approx. 406
Ч
431.5
Ч
420 mm (w/h/d)
(16
Ч
17
Ч
16
5
/
8
inches)
Mass
Approx. 18.5 kg (40 lb 13 oz)
Pin assignment
Video signal cable (HD15) (Male)
The cable accepts RGB video signals (0.7 Vp-p, positive),
and SYNC signals.
5
4
3
2
1
8
7
6
15
14
13
12
11
10
9
Pin No.
1
2
3
4
5
6
7
Signal
Red
Green
(Composite
Sync on Green)
Blue
Ground
Ground
Red Ground
Green Ground
Pin No.
8
9
10
11
12
13
14
15
Signal
Blue Ground
—
Ground
Ground
Bi-Directional
Data (SDA)
∗
H. Sync
V. Sync
Data Clock (SCL)
∗
∗
As defined by Display Data Channel (DDC) Standard by
VESA.
Note
Design and specifications are subject to change without notice.
