Package Contents
•
4-Port RS232 Serial PCI with 16550 UART
•
Slot bracket with 2 DB9 (9-pin) serial
ports
•
Driver CD
•
Quick installation guide
Layout
Figure 1: Layout
Note
: Make sure the stripe on the ribbon cable is
align to the pin 1 of the serial header when
connected for proper connection.
Serial port 1 (COMA)
Serial port 2
(COMB)
Serial port 3
(COMC)
Serial port 4 (COMD)
Stripe
Stripe
Connector bracket
with 9-pin serial port
