Additional Information 86
Front panel, with cover opened
1 Display window (33)
2 VIDEO 2 INPUT VIDEO/AUDIO L/R jacks (12)
3 EASY SET UP button (14)
4 TIMER REC button (38)
5 QUICK TIMER button (71)
6 RF CHANNEL button (13)
7 AUDIO DUB button (78)
8 STANDBY DISPLAY ON/OFF switch (12)
9 VTR COMMAND MODE OFF/1/2/3 selector (47)
0 Tape operation indicators
Display window 1 Video input indicators (45)
2 TIMER indicator (38, 41, 71)
3 REC indicator (71)
4 (audio dubbing) indicator (78)
5 VTR indicator (14)
6 OPC indicator (75, 76)
7 PDC indicator (41)
8 EDIT indicator (77)
9 STEREO indicator (72)
0 NICAM indicator (72)
! ¡ RF indicator (13)
!™ RF channel (13)/line/programme position indicator
(35)
! £ Time counter/clock/operating function/sound field
indications (33)
! ¢ Tape speed indicators (35)
! Ò (tape) indicator
Index to parts and controls
(continued)
AUTO TRACKING
TIMER
LINE
VIDEO1
VIDEO2
REC
LP EP SP
VTR OPC PDC EDIT STEREO NICAM RF
H M S
