LF220 - Parts list
M8 x 45mm
M6 x 40mm M4 x 30mm
14mm 24mm
M4 x 12mm M6 x 14mm
M8 x 16mm
[01] x 1 [02] x 1 [03] x 1
[04] x 4 [05] x 4 [06] x 4
[09] x 4 [08] x 4
[07] x 4
[10] x 4
[13] x 1
[11] x 4
[14] x 4
[12] x 4
[15] x 4
10 mm
(3/8 in.)
5.5mm
(7/32 in.)
13 mm
(1/2 in.)
[16] x 4
[17] x 4
[18] x 4
[19] x 4
[20] x 4
[21] x 2 [22] x 2
[24] x 1 [23] x 1
5/16 x 3.5 in.
3/16 in. 5/32 in.
Supplied Parts and Hardware
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged
item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: M4, M6, or M8 describes the diameter, mm describes the length of screws that are labeled M0 X 00mm. Not all hardware included
will be used.
Required Tools
