BIOS Setup Utility SY-7VCA
57
3-1.1 Quick CPU Frequency Setup
Quick CPU
Frequency Setup Setting Description Note
HW Default 120/40 MHz
66/33 MHz
124/31 MHz
68/34 MHz 126/31 MHz
75/37 MHz 129/32 MHz
80/40 MHz 133/33 MHz
83/41 MHz 135/33 MHz
85/28 MHz 138/34 MHz
90/30 MHz 140/35 MHz
95/31 MHz 141/35 MHz
100/33 MHz 143/35 MHz
103/34 MHz 145/36 MHz
105/35 MHz 147/36 MHz
109/36 MHz 150/37 MHz
112/37 MHz 154/38 MHz
114/38 MHz 160/40 MHz
115/38 MHz 166/41 MHz
CPU Host/PCI
Clock
118/39 MHz
Select the host clock of your
Slot 1 processor among these
values.
Note: For the Via 694X
chipset, 66 and 100 and
133 MHz host clock
frequencies are acceptable.
However, the system
stability is not guaranteed
for other frequencies due
to the limitations of this
chipset.
CPU Ratio After you have selected the host clock, choose the right
multiplier for the CPU. Options are: [2, 2.5, 3., 3.5, 4, 4.5, 5,
5.5,6,6.5,7.0,7.5,8.0]. The CPU frequency is then defined as
[host clock freq.]x[multiplier], and should the working
frequency of your Pentium
® III & Pentium ® II processor.
3-1.2 C.I.H. 4-WAY Protection Settings
Setting Description Note
Disabled C.I.H. 4-
WAY
Protection
Enabled
When set to enabled, the BIOS can
only be programmed through
AWDFLASH, making sure that any
virus is unable to program the system
BIOS. Set to disable the BIOS can be
programmed the traditional way.
Default
