• 10 •
PROBLEM POSSIBLE CAUSE SOLUTION
Indicator lights are lit in
an erratic manner, not
explained in the Operating
Instructions.
A button may have been
pressed while the charger
was being plugged in.
Make sure nothing is
touching the control panel,
then unplug the unit and
plug it in again.
The measured current is
much lower than what was
selected.
The charger reached the
maximum voltage and is
reducing the current.
No problem; this is a normal
condition.
Charger will not turn on
when properly connected.
AC outlet is dead.
Poor electrical connection.
Check for open fuse or
circuit breaker supplying AC
outlet.
Check power cord and
extension cord for loose
fitting plug.
Battery clips do not spark
when touched together.
The charger is equipped
with an auto-start feature. It
will not supply current to the
battery clips until a battery is
properly connected. Unlike
traditional chargers, the
clips will not spark if touched
together.
No problem, this is a normal
condition.
BEFORE RETURNING FOR REPAIRS 16.
When a charging problem arises, make certain that the battery is capable of accepting 16.1
a normal charge. Use a good battery to double check all connections, AC outlet for a full
120-volts, charger clips for correct polarity and the quality of the connections from the
cables to the clips and from the clips to the battery system. The clips must be clean.
When a battery is very cold, partially charged or sulfated, it will not draw the full rated
16.2
amperes from the charger. It is both dangerous and damaging to a battery to force
higher amperage into it than it can effectively use in recharging.
When an UNKNOWN OPERATING PROBLEM arises, please read the complete manual
16.3
and call the customer service number for information that will usually eliminate the need
for return.
If the above solutions do not eliminate the problem or for information
about troubleshooting, call toll-free from anywhere in the U.S.A.
1-800-621-5485
7:00 am to 5:00 pm Central Time Monday through Friday
LIMITED WARRANTY 17.
WARRANTY NOT VALID IN MEXICO.
SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS CENTER DRIVE,
MOUNT PROSPECT, IL 60056-2179, MAKES THIS LIMITED WARRANTY TO THE
ORIGINAL RETAIL PURCHASER OF THIS PRODUCT. THIS LIMITED WARRANTY IS
NOT TRANSFERABLE OR ASSIGNABLE.
Schumacher Electric Corporation (the “Manufacturer”) warrants this battery charger for 5
years from the date of purchase at retail against defective material or workmanship that
may occur under normal use and care. If your unit is not free from defective material or
workmanship, Manufacturer’s obligation under this warranty is solely to repair or replace
your product with a new or reconditioned unit at the option of the Manufacturer. It is the
obligation of the purchaser to forward the unit, along with mailing charges prepaid to the
Manufacturer or its authorized representatives in order for repair or replacement to occur.
Manufacturer does not provide any warranty for any accessories used with this product
that are not manufactured by Schumacher Electric Corporation and approved for use
with this product. This Limited Warranty is void if the product is misused, subjected to
careless handling, repaired, or modified by anyone other than Manufacturer or if this unit
is resold through an unauthorized retailer.
Manufacturer makes no other warranties, including, but not limited to, express,
implied or statutory warranties, including without limitation, any implied warranty
