Sharp XL-3000V - Manual (Page 72)

XL-3000V
Figure SPEAKER EXPLODED VIEW
A
B
C
D
E
F
G
H
1 2 3 4 5 6
SP3 (L-CH)
SP4 (R-CH)
SP1 (L-CH)
SP2 (R-CH)
SP3 (L-CH)
SP4 (R-CH)
Tweeter
Tweeter
Capacitor
909
Capacitor
3.3
µ
F,50V
(N.P)
SP1 (L-CH)
SP2 (R-CH)
SP3,4
SP1,2
Woofer
Woofer
Black
Black
White Line
White Line
909
909
902
908
907
910x2
910x4
906
901
903
905x2
905x2
904
