– 15 –
XL-3000V
Checking of vector scope waveform
Checking Setting Disc Checking
Item
Track 2 VIDEO OUT Set the phase of Phase check
color burst signal
±
10
°
(B) to 180 ° -360 °
line.
( Check that the setting is within the illustrated range.)
Checking the black-and-white level
Track 16 VIDEO OUT Output level
100
±
10 IRE
Checking Checking Item Disc
YL
MG
CY G
75%
B
R-Y
-Q
-I
[NTSC] [PAL]
I
Q
YL
R
R
75%
B-Y
MG
B
CY
cy
G
mg
U
V
g
yl
b
100IRE
40IRE
40IRE
100% Luminance
Horizontal Interval
reference signal 100% WHITE LEVEL
Figure 15-1
Figure 15-2
