Installation requirements 7
Electrical
•
Machine Voltage/Amperage - 120V, 60 Hz,
1300 W, 10.5 Amp.
•
Connection - 3-prong plug with 6’ cord is
provided with the machine.
•
Circuit/Protector - 3-wire single phase, 120V,
60 Hz, AC, on a separate 15 Amp circuit.
Location
•
This machine may be installed free
standing as well as in a recessed area,
closet, or alcove
•
Minimum Installation Spacing - 0” on
sides and 1” in front and back. NOTE:
Additional installation spacing needs to be
considered for easy installation, servicing,
and compliance with state and federal
codes.
•
Floor - Must support at least 280 lbs. and
be a solid, level surface. DO NOT install on
carpet.
•
RV/Marine Installations - When locating
the appliance in a towable trailer or
watercraft, position the machine over the
axles or mid-ship where movement is at a
minimum. Block the machine to prevent
extreme movement.
•
Exhaust Requirements - Rigid or flexible
metallic duct required. Ducting should be
as short and straight as possible. DO NOT
exhaust dryer into a chimney, furnace, cold
air duct, attic crawl space, or another duct
used for venting. If a cabinet door is
installed, a minimum of 8 sq. in. should be
provided for make up air. Louvered doors
with equivalent air openings are
acceptable. Allow clearances behind
door(s) to avoid rubbing between back of
cabinet door(s) and front of unit control
panel. Additional clearances for wall, door
and floor moldings may be required.
Drainage
Standpipe Diameter/Capacity - Needs a 1 ¼”
minimum diameter standpipe with a minimum
carry-away capacity of 7 gallons per minute.
Top of Standpipe - Must be between 25” and 34”
high from the bottom of the machine.
Outlet End of Drain Hose (provided with the unit)
- Must be at least 20” above the bottom of the
washer-dryer. An air break must be available at the
standpipe to avoid siphoning. No more than 6” of
the drain hose should be inserted into the drain
pipe to prevent siphoning.
If you have... You’ll need...
no access to Hot/Cold
water hookups Splendide Faucet Adapter
Kit, or equivalent.
to install a dryer vent
and ducting in your
RV or boat
concerns about the
appliance shifting in
your RV or boat
water damage
concerns
to make a 90” duct
turn in less than 4.5”
Splendide Vent Kit, or
equivalent.
Splendide SecureFit bracket
kit, or equivalent.
Splendide Drain-A-Way Pan,
or equivalent.
Splendide 90˚ offset elbow, or
equivalent.
