-19
Setup
Projection (PRJ) Mode
The projector can use any of the 4 projection modes, shown in the diagram below. Select the mode most appro-
priate for the projection setting in use. (You can set the PRJ mode in “Options2” menu. See page
52 .)
■ Table mounted, front projection ■ Ceiling mounted, front projection
[Menu item
➞ “Front”]
[Menu item
➞ “Ceiling + Front”]
■ Table mounted, rear projection ■ Ceiling mounted, rear projection
(with a translucent screen) (with a translucent screen)
[Menu item
➞ “Rear”]
[Menu item
➞ “Ceiling + Rear”]
Indication of the Projection Image Size and Projection Distance
For details, refer to the “SETUP MANUAL” contained on the supplied CD-ROM.
Example: NORMAL Mode (4:3) for standard lens
500"
200"
100"
84"
60"
400"×300"
Projection Distance
160" Ч
120"
80" Ч
60"
67" Ч
50"
48" Ч
36"
58'7
"–70'4
"
(17.9 m – 21.4 m)
23'5
"–28'1
"
(7.1 m
– 8.6 m)
11'9
"–14'1
"
(3.6 m
– 4.3 m) 9'10
"–1
1'10
"
(3.0 m
– 3.6 m) 7'0
"–8'5
"
(2.1 m – 2.6 m)
Picture Size
