Hooking up the Component Video Switcher
Before hooking up the Component Video Switcher, be sure the AC power cord is unplugged.
Refer to the illustration below for the connection.
Speaker
 The CAT5 cable can extend up to 300 feet.
Audio/Video
Source 1 ~ 8
Component Video
Audio L/R
CAV-M1000ES
CAV-M1000ES
CAV-CVS12ES
RS-232C cable
RS-232C cable
CAT5 cable 
Component Video Balun
CAV-CVB1
Keypad
Zone 1 ~ 12 Display
Speaker
Component Video
cable
Audio/Video
Source 9 ~ 12
(VHS, etc.)
Audio L/R
Composite
Video
