Assembly Pack Check List (EL3)

Step 1

M5 x 15m/m

Phillips Head Screw

(6pcs)

3/8" x 2-1/4"
Hex Head Bolt (2pcs)

3/8" x 19 x 1.5T
Flat Washer (2pcs)

M5x12m/m

Phillips Head Screw

(4 pcs)

3/8"x23x2T
Curved Washer (2pcs)

3/8"x2T

Split Washer

(1pc)

3/8" x 23 x 2T
Curved Washer (4pcs)

3/8" x 3/4"
Hex Head Bolt (2pcs)

3/8" x 2-1/4"
Hex Head Bolt (1pc)

3/8" x 3-3/4"
Hex Head Bolt (4pcs)

Step 2
