Sanyo PLC-XF1000 - Manual (Page 14)

Remote Control
Part Names and Functions
q
t
e
!0
i
!4 r
!3
!1
w
y
u
o
!7
!2
!8
!9
@0
e LIGHT button
Light the buttons on the remote control for about 10
seconds.
r MENU button
Open or close the On-Screen MENU (pp.25-26).
t
POINT ed 7 8 buttons
– Select an item or adjust the value in The ON-SCREEN MENU (p.25).
–Pan the image in DIGITAL ZOOM + mode (p.40).
y
LENS SHIFT button
Select the LENS SHIFT function (p.29).
u
FOCUS buttons
Adjust the focus (p.29).
i
ZOOM buttons
Zoom in and out the images (p.29).
o FREEZE button
Freeze the picture on the screen (p.29).
!1 P-TIMER button
Operate the P-TIMER function (p.30).
!2 KEySTONE button
Correct keystone distortion (pp.30, 40, 44).
q ON/STAND-By button
Turn the projector on or off (pp.23-24).
w AUTO PC button
Automatically adjust the computer image to its optimum
setting (pp.29, 35).
!4 SHUTTER button
Close the built-in shutter for light blocking (pp.27, 30).
!5 SELECT button
–Execute the selected item (p.25).
– Expand or compress the image in the DIGITAL ZOOM mode
(p.40).
@1 wired Remote jack
Connect the remote control cable (not supplied) to this jack
when using as a wired remote control.
@0 IMAGE SEL . button
Select the image level (pp.30, 38, 42).
!8 INPUT 1, 2, 3, 4 buttons
Select an input source (pp.31-33).
!7 IMAGE ADj . button
Enter the image level adjustment mode (pp.30, 45-47).
!9 INFO . button
Display the input source information (p.29).
!6 SCREEN button
Select the screen size (pp.39-40).
!0 D .ZOOM button
Select the Digital zoom +/- mode and resize the image (pp.29, 40).
14
✔
Note:
To ensure safe operation, observe the
following precautions:
• Do not bend, drop, or expose the remote
control to moisture or heat.
• For cleaning, use a soft dry cloth. Do not
apply benzene, thinner, spray, or any other
chemical materials.
!3 FILTER button
Scroll the filter (p.30).
@1
!5
!6
