18
Audio Input Audio Input
Connectors XLR and 1/4" TRS jack
Impedance 20k Ohm balanced, 10k Ohm unbalanced
Nominal Operating Level
Max. Input Level +21 dBu, balanced and unbalanced
CMRR Typ. 40dB, >55dB @ 1kHz
Audio Output Audio Output
Connectors XLR and 1/4" jack
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level +21 dBu, balanced and unbalanced
Power Supply Power Supply
Mains Voltages/selectable USA/Canada ~120 V AC, 60 Hz
U.K./Australia ~240 V AC, 50 Hz
Europe ~230 V AC, 50 Hz
Fuse 100-120 V AC; 250 mA (slow-blow)
200-240 V AC: 125 mA (slow-blow)
Power Consumption 5 Watts
Power inlet Standard IEC receptacle/with fuse
Size
Dimensions 1 3/4" (44.5 mm)H x 19" (482.6 mm) x 7 3/4" (196.9 mm)
Weight Weight
Net Weight 5.25 lbs.(2.4 kg)
Shipping Weight 7.5 lbs.(3.4 kgs)
Specifications
